Mondraker ANARK XR 2026 Super Enduro Bike
Built for bike park laps, freeride days and full-send fun
The Mondraker ANARK XR 2026 is built for riders who want a long-travel gravity bike that still keeps a playful edge. With 180mm front travel, 170mm rear travel, a mullet wheel setup and Mondraker’s updated Zero Suspension System, it is aimed squarely at bike park riding, freeride sessions and aggressive descending.
The ANARK takes plenty of inspiration from Mondraker’s downhill development, but it is not trying to be a full race bike. It is about speed, grip and stability when the trail points down, while still keeping the kind of lively, fun ride feel that makes you want one more lap.
Key Features
- Anark 6061 Alloy Stealth Evo frame
- Updated Zero Suspension System
- 180mm Öhlins RXF 38 M.3 fork
- 170mm rear travel
- Öhlins TTX 22M.2 Coil rear shock
- SRAM 90 Eagle T-Type 12-speed drivetrain
- SRAM Maven Base 4-piston brakes
- e*thirteen Grappler Core wheelset
- Mullet setup with 29" front and 27.5" rear
- Flip chip geometry adjustment
- 170mm travel super enduro / freeride platform
Why It Stands Out
The ANARK XR is all about the kind of riding where speed, support and confidence matter, but where having fun still comes first. The long-travel Öhlins setup gives it a really planted feel on rough terrain, while the mullet wheel layout helps keep the bike more agile and easier to move around than a full 29er gravity rig.
It is also built around a very solid component package. SRAM T-Type shifting, Maven brakes and tough e*thirteen wheels make sense on a bike that is designed to be ridden hard, and the geometry adjustment gives you some room to tune the bike depending on the kind of tracks you ride most.
Specifications
| Category | Specification |
|---|---|
| Model | Mondraker ANARK XR 2026 |
| Price | £5,399 |
| Frame | Anark 6061 Alloy Stealth Evo, Mullet, hydroformed tubing, Updated Zero Suspension System, 170mm travel, Forward Geometry, one-piece Monoblock upper link, Boost 12x148mm rear axle, UDH, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, internal dropper routing, Max. capacity sealed bearings, ISCG 05 |
| Frame Sizes | S / M / ML / L / XL |
| Fork | Öhlins RXF 38 M.3 29, 180mm, TTX18 Twin Tube cartridge, Boost 15x110mm axle, 44mm offset |
| Rear Shock | Öhlins TTX 22M.2 Coil, 205x65mm |
| Shock Spring Rate | S: 343 lbs / M: 411 lbs / ML: 457 lbs / L: 502 lbs / XL: 502 lbs |
| Front Travel | 180mm |
| Rear Travel | 170mm |
| Wheel Setup | Mullet |
| Front Wheel Size | 29" |
| Rear Wheel Size | 27.5" |
| Headset | Onoff custom ZS56 / ZS56, 1-1/8" / 1.5" |
| Stem | Onoff S6, 30mm, 0º |
| Handlebar | Onoff S6 1.0 7050 alloy, 800mm, 25mm rise, 8º backsweep, 5º upsweep |
| Grips | Onoff Desert Pro lock-on |
| Seatpost | Onoff Pija internal dropper, size specific travel |
| Saddle | Ergon Enduro SPS20 |
| Front Brake | SRAM Maven Base, 4-piston, 200mm rotor |
| Rear Brake | SRAM Maven Base, 4-piston, 200mm rotor |
| Brake Lever | SRAM Maven Base |
| Rims | e*thirteen Grappler Core, IW30 hookless, 30mm internal width, tubeless ready |
| Spokes | e*thirteen custom Hive triple-butted black steel |
| Front Hub | e*thirteen Boost 15x110mm, IS 6-bolt |
| Rear Hub | e*thirteen Boost 12x148mm, IS 6-bolt, HG freehub |
| Front Tyre | Maxxis Assegai 29x2.5WT, 3C MaxxGrip, DH casing, tubeless ready |
| Rear Tyre | Maxxis Minion DHR II 27.5x2.5WT, 3C MaxxTerra, DH protection, tubeless ready |
| Crankset | SRAM 90 T-Type, Boost, DUB axle, direct mount chainring |
| Chainring | 32T alloy T-Type |
| Bottom Bracket | SRAM DUB BSA, 73mm |
| Chain | SRAM 70 T-Type, 12-speed |
| Rear Derailleur | SRAM 90 Eagle T-Type, 12-speed |
| Shifter | SRAM Trigger 70, 12-speed, T-Type actuation |
| Cassette | SRAM XS-1270, 10-52T, 12-speed |
| Claimed Weight | 17.9kg |
Geometry Highlights
| Feature | Details |
|---|---|
| Head Angle | 63.5° standard / 63.15° low |
| Bottom Bracket Height | 345.5mm standard / 341mm low |
| Seat Angle | 77° standard / 76.65° low |
| Chainstay Length | 445mm standard, with 1mm change via flip chip |
| Flip Chip | Single-bolt standard / low geometry adjustment |
| Five Sizes | S / M / ML / L / XL |

The ANARK XR is built around a fun-first gravity setup, so it is aimed more at bike park, freeride and descending-focused riding than big all-day pedalling missions.
